iFlight BNF iH3 HD 4S 3.5" H-shaped Quad w/DJI O3 Air Unit & Micro Cam - ELRS 2.4GHz (GPS)

• DJI O3 HD Air Unit Low-Latency digital transmission

• 4K Stabilized Video with 155° Ultra-Wide Angle

• Secured Battery Plug with Anti-Spark Filter

• GPS Pre-Installed on a foldable mount for More Safety at A Distance
• Special canopy to carry naked GoPro or Gopro Bones.

• The H-shaped frame structure for balance, no props in view.
• Up to 14min Cruise Time
• Anti-Spark Filter ensure balance and stability even during intense operations, no props in view.

Specifications

• Product Name: iH3 O3 4S HD BNF

• FC: BLITZ Mini F7 FC

• ESC: BLITZ Mini E55 4-IN-1 ESC

• Video Transmission: DJI O3 Air Unit

• Geometry: H-Shaped

• Frame: 168 mm (wheelbase)

• Motor: XING 1504 3100Kv motors

• Prop: HQ 3.5 x 2.5 x 3 propellers

• Weight of the Aircraft: Approx. 216g (Without Battery)

• Dimensions (L×W×H): 135 x 100 x 40 mm (From Canopy)

• Max Speed: 110 Km/h (Manual Mode)

• Maximum Takeoff Altitude: 3200m

• Max Wind Speed Resistance: Level 5

• Operating Temperature Range: -10° to 40° C (14° to 104° F)

• Antennas: DJI O3 Air Unit Dual-band Antenna
• GNSS: GPS+Galileo

VTX SPECIFICATIONS:

• Weight: Approx. 36.4 grams（headband included）

• Dimensions (LxWxH): L32.5 x W30.5 x H 14.5mm

• Communication Bandwidth： Max 40 MHz

• FOV (single screen): 155°

• Communication Frequency: 2.400-2.4835 GHz；5.725-5.850 GHz

• End-to-End Latency
• With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms.
• With DJI FPV Goggles V2: 810p/60fps Video Transmission Quality: The latency is lower than 40 ms.
• With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms.

• With DJI Goggles 2: 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms.
• Max Video Transmission Bitrate: 50 Mbps
• Max Video Transmission Range 10 km (FCC), 2 km (CE), 6 km (SRRC)

• Operating Temperature Range: -10º to 40º C (14° to 104° F)

• Power Input: 7.4-26.4 V

• Audio Transmission: N/A


Includes

• 1x iFlight BNF iH3 HD 4S 3.5" H-shaped w/DJI O3 Air Unit & Micro Cam - ELRS 2.4GHz (GPS)
• 1x DJI O3 Air Unit Antenna

• 1x Battery pads

• 1x Set of HQ 3.5x2.5x3 propellers

• 1x Screw Bag

• 1x Naked Gopro Cable
